ZF 16S ECOSPLIT GEARBOX FOR HEAVY TRUCKS 16F + 2R Cutaway Model

Order Code: AT0252

Category: Automobile Engineering & I.C. Engine Lab

Description The gearbox is composed of a central box containing 4 forward speeds gearings and 2 reverse speeds gearings, an epicyclic unit for selecting the speed-gears mounted on the base, and an over-gear on top. The over-gear allows dividing each...



SPECIFICATION

Description
The gearbox is composed of a central box containing 4 forward speeds gearings and 2 reverse speeds gearings, an epicyclic unit for selecting the speed-gears mounted on the base, and an over-gear on top. The over-gear allows dividing each gear into slow or fast obtaining 16 forward gears which can be inserted and geared down in sequence.

  • Heavy vehicles gearbox
  • With the possibility of selecting any speed
  • Operated manually through a hand wheel;
  • Gearbox cutaway model on stand with wheels;
  • Weight approx. - 400 kg

Equipment for technical and vocational Tesca education and training.
