Wide Band Amplifier (V.V.)

Order Code: 36117

Has been designed specifically for the study of Wide Band Amplifier. Practical experience on these boards carries great educative value for Science and Engineering Students. Object: To study Wide Band Amplifier for : Frequency Response of ...

SPECIFICATION

Has been designed specifically for the study of Wide Band Amplifier.
Practical experience on these boards carries great educative value for Science and Engineering Students.

Object:
To study Wide Band Amplifier for :

Frequency Response of uncompensated Amplifier.
Low Frequency compensation.
High Frequency compensation.
Phase response of compensated and un-compensated amplifier.

Features:
The board consists of the following built-in parts :

A valve with base fixed on panel and wired internally.
Adequate no. of other electronic components.
Adequate no. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ metre.
Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections/ observation of waveforms.
Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
Weight : 3 Kg. (Approx.)
Dimension : W 340 x H 110 x D 210

Other Apparatus Required:

IC Regulated Power Supply
Decade Audio Frequency Generator
R.F. Signal Generator
A.C. Millivoltmeter
Decade Condenser Box
Decade Resistance Box
Cathode Ray Oscilloscope 20MHz
