Universal PLC (Siemens) Trainer Digital 8 Input 6 Output

Order Code: 21225385.83

Category: General Lab Equipment I

The PLC universal system simulator should be compact and constructed according to the motto ""set up, switch on and train"". It should exceptionally well-suited to graphically demonstrate open-loop and closed-loop industrial ap...



SPECIFICATION

The PLC universal system simulator should be compact and constructed according to the motto ""set up, switch on and train"".

It should exceptionally well-suited to graphically demonstrate open-loop and closed-loop industrial applications.

By using the masks up to 24 different technical processes and models should be simulated.


Trainer kit to verify

  •  The system should cover at least the following topics:
  •  Construction caution light
  •  Star-delta starting
  •  Dahlander circuit
  •  Starter control
  •  Monitoring device
  •  Reservoir - filling system
  •  Gate control of a lock
  •  Re-rooting platform
  •  Buffer storage
  •  Filling level controlled system
  •  Mixer system
  •  Compressed air network
  •  Cleaning bath
  •  Oven door control
  •  Bending tool
  •  Stamping machine / automatic
  •  Drilling mechanism
  •  Selective distributor
  •  Tube bending plant
  •  Gate control
  •  Pump control
  •  Reaction chamber
  •  Automatic tablet packer Specs
  •  At least 8 digital inputs (actuators)
  •  At least 20 digital outputs (sensors)
  •  At least 2 analog inputs (actuators)
  •  At least 2 analog outputs (sensors)
  •  At least 3 running lights
  •  Connections realised on 4mm safety sockets
  •  1 connector (input signals) for the connection to PLC via system connector
  •  1 socket (output signals) for connection to the PLC via the system connector
  •  Operating voltage: DC 24V/0.3A
