Universal Table (PLC BASED): X=200mm, Y=200mm, Z=150mm, ?= -45º to +45º - using Servo motors & Servo Amplifier
Order Code: 52377
Category: Process Control Trainers
The Universal Table trainer gives provision to interface PLC with four axis displacement of the table. Features Controlled by PLC Table can be moved in Horizontal, Vertical Direction and can also be tilted. Table travel: X-200, Y-200, Z-...
SPECIFICATION
The Universal Table trainer gives provision to interface PLC with four axis displacement of the table.
Features
- Controlled by PLC
- Table can be moved in Horizontal, Vertical Direction and can also be tilted.
- Table travel: X-200, Y-200, Z-150%u04E8 -45° to 45°.
- Load carrying capacity-10Kg, with ball lead screw, Minidrill-dia.8mm, Drill-Vice.
Experiments
- To move MS table in Horizontal, Vertical direction and also Tilt with the help of PLC ladder program & Stepper motor driven mechanism.
- Equipment Required
- PLC Micrologix 1200 with PWM output.
Specifications
- Servo motors
- Servo Amplifier
- PLC:- Allen Bradely Micrologix-1200 762124BXB. DI:-14, DO:-10,PC-PLC cable, RS Logix-500 ladder prog. Software.
- Lead/Ballscrew linear guideways mechanical mechanism for X-Y, UP-DOWN, TILT movement Of a table.
Services Required
- Single Phase 230 VAC 50 HZ Supply
