Turbidimeter

Order Code: 19203631.5.3

Category: General Lab Equipment III

Turbidimeter kit with USB and Power module Specifications:  Accuracy: ± 2% of reading plus stray light  Battery requirements: 4, AA  Certifications: CE certified  Compliance Certifications: CE/WEEE  Data...



SPECIFICATION

Turbidimeter kit with USB and Power module
Specifications:

  •  Accuracy: ± 2% of reading plus stray light
  •  Battery requirements: 4, AA
  •  Certifications: CE certified
  •  Compliance Certifications: CE/WEEE
  •  Data logging: 500 records
  •  Dimensions (H x W x D): 77 mm x 107 mm x 229 mm
  •  Display size: 240 x 160 pixels
  •  Display type: Graphic LCD
  •  Enclosure rating: IP67
  •  Height: 3.0 in
  •  Includes: Instrument, case assembly, 4 AA alkaline batteries, 6 sample cells with caps, StablCal ampule kit (stab calibration standards), silicone oil, oiling cloth, manual.
  •  Interface: USB
  •  Light source: Tungsten filament lamp
  •  Manual languages: English, French, German, Italian, Spanish, Portuguese (BR), Portuguese (PT), Bulgarian, Chinese, Czech, Danish, Dutch, Finnish, Greek, Hungarian, Japanese, Korean, Polish, Romanian, Russian, Slovenian, Swedish, Turkish
  •  Max. operating humidity: 90 %
  •  Measurement Method: Ratio turbidimetric determination using a primary nephelometric light scatter signal (90°) and transmitted light scatter signal.
  •  Measurement Modes: Normal (Push to read), signal averaging, rapidly setting turbidity
  •  Operating temperature range: 0 – 50 °C
  •  Power requirements: 100 – 240 VAC, 50/60 Hz (with included USB + power module)
  •  Power supply: Batteries (4, AA)
  •  Range: 0 – 1000 • Rang 2: NTU
  •  Reading modes: Normal (Push to read), signal averaging, rapidly setting turbidity
  •  Regulatory: EPA method 180.1
  •  Repeatability: ± 1% of reading or 0.01 NTU, whichever is greater
  •  Response time: 6 sec in normal reading mode
  • Sample cell compatibility: 25 mm x 60 mm round
  •  Sample requirements 15 mL 90.5 oz)
  •  Sample volume: 15 mL (0.5 oz)
  •  Signal averaging: Selectable on/off
  •  Storage conditions: -40 °C to 60 °C
  •  Stay light: < 0.02 NTU
  •  Units: NTU
  •  User interface: Button graphic user interface
  •  User interface languages: English, French, German, Italian, Spanish, Portuguese (BR), Portuguese (PT), Bulgarian, Chinese, Czech, Danish, Dutch, Finnish, Greek, Hungarian, Japanese, Korean, Polish, Romanian, Russian, Slovenian, Swedish, Turkish
  • Warranty: 1 year
