Trinocular Microscope with USB Support and Camera

Order Code: 21224975.22

Category: General Lab Equipment II

Achromatic HC type 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25 (oil/water) All with anti-fungus treatment. Specimen stage: Mechanical stage, 125×115 mm, 70×30 mm X-Y movement range. Vernier scale on the two axes Accuracy: 0.1 mm.



SPECIFICATION

Specifications:-

  • Head: Trinocular (split ratio: 50/50), 30° inclined; 360° rotating.
  • Dioptric adjustment: Left eyepiece.
  • Eyepieces: WF10x/18 mm, high eyepoint, secured by screw.
  • Nosepiece: Quadruple ball bearings revolving nosepiece, reversed.

Objectives:

  • Achromatic HC type 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25 (oil/water)
  • All with anti-fungus treatment.
  • Specimen stage: Mechanical stage, 125×115 mm, 70×30 mm X-Y movement range.
  • Vernier scale on the two axes
  • Accuracy: 0.1 mm.
  • Focusing: Coaxial coarse and fine focusing mechanism with limit stop to prevent the contact between objective and specimen. Adjustable tension of coarse focusing knob.
  • Condenser: 1.25, per-centered, focus able, with iris diaphragm.
  • Illumination: X-LED² with white 3 W LED and brightness control. Color temperature: 6,300 K. Multi-plug 100-240Vac/6Vdc external power supply.
  • USB 2.0 C-mount and Eyepiece Microscope Camera
  • USB output: Yes
  • C-Mount:Yes
  • CS-Mount: No
  • Camera resolution (n° of pixels: W x H): 2048x1536
  • Color / Monochrome Color
  • Sensor Size 1/2"
  • Sensor Technology: CMOS
  • Sensor Type: APTINA CMOS
  • Image Format: 4/3
  • Pixel Size (mm): 3.2x3.2
  • Acquisition technology Rolling shutter
  • Sensitivity: 1 V/lux-second
  • Signal/Noise Ratio (DB): 43
  • Dynamic range (DB): 61
  • ADC conversion 8 Bit
  • Color Depth: 1, 4, 8, 24 Bit
  • Exposure time: 0.244 msec - 2 sec
  • Binning: 1x1; 2x2; 3x3
  • IR filter: Yes
  • IR filter range (nm): 380-650 (IR CUT)
  • PC Camera resolution (MP): 3.1
  • USB standard USB2.0
  • Frame rate full resolution (fps) 12@2048x1536 Frame rate other resolution (fps) 32@1024x768; 45@680x510
  • Connector USB
  • Output voltage PC USB
  • Optical adapter (for 23mm eyepiece tube): 0.5x
  • Adapter ring: Yes
  • Diameter of adapter ring (mm): 30
  • Diameter of adapter ring (mm): 30.5
  • Calibration slide: Yes
  • Camera Power Supply
  • Camera accessories
  • Sensor: USB
  • Working Temperature: -10°C up to +50°C
  • Storage Temperature: -20°C up to +60°C
  • Relative Humidity 30% to 80%
  • Storage Humidity 10% to 60%
  • OS Windows 7 ,OS Windows 8 ,OS Windows 10 (32Bit) ,OS Windows 10 (64Bit) ,OS Osx (MAC Osx) starting from 10.7.5 ,OS Linux ,PC SW PROVIEW ,PC SW LITEVIEW ,PC CPU: Intel Core2 - 2.8GHz or higher PC RAM: 2GB
