Testing of static distance protection relay using Relay Testing Kit.
Order Code: 24257890.19
Category: General Lab Equipment V
Numerical Distance Protection Relay Test Setup Supply Scope: The system is designed to test and demonstrate the functionality of an industrial-grade numerical distance protection relay. It includes all necessary accessories and protective featu...
SPECIFICATION
Numerical Distance Protection Relay Test Setup
Supply Scope:
The system is designed to test and demonstrate the functionality of an industrial-grade numerical distance protection relay. It includes all necessary accessories and protective features for safe and effective operation.
Components Included:
-
Original industrial-grade numerical distance protection relay
-
BTI connectors / BS-10 / BS-2 as required for interface connections
-
Built-in fuse protection and overcurrent protection for system safety
-
Control Switches:
-
Start Push Button
-
Stop Push Button
-
Reset Switch
-
-
Trip Status Indicator for visual status monitoring
-
Auxiliary Power Supplies:
-
24V SMPS unit
-
230V AC auxiliary source
-
-
DC Relay Output terminals with NO (Normally Open) / NC (Normally Closed) connection options
-
Current Injection Set and Variable Voltage Supply for relay testing
-
Digital Panel Meters:
-
Ammeter
-
Voltmeter
-
Elapsed Time Counter
-
-
Complete set of patch cords and power cables included for full system operation
