Features:

• Quink's tube is provided with measuring scale

• Provided with a magnifying lens

• Gauss and Tesla meter for measuring magnetic field with LCD and PC interface facility

• InAs Probe for better sensitivity of magnetic field

• Provided with an Electromagnet

• Provided withthe Constant Current Power Supply foran Electromagnet

• Online product tutorials and manual should be available to perform lab experiments by following step-by-step experimental procedure

Technical Specifications:

• Quinck's Tube It is a U-shaped glass tube.

• One of the limbs of the tube is wide and the other one is narrow.

• Wide limb of the tube is fitted with the stand.

• Paramagnetic samples It includes with two paramagnetic material one is Ferric Chloride (Fecl ) and other is Mangnese Sulphate (MnSo ).

• Electromagnet: Poles : 25 mm diameter Coils : 2 No.

• Resistance : 2.2 Ohms (approx.)

• Yoke : Ushaped softiron material

• Input voltage : 40 V, 3.5 A

• Constant current power supply Current range : 0 to 3.5 A

• Output Voltage : 40 V

• Display : 3½ digit, 7 segment

• Mains : 230 V,

• Gauss and Tesla meter Microcontroller Based LCD Display For Measurement of Magnetic Field in Gauss and Tesla, With PC Interface facility.

• It can indicate the direction of the magnetic field.

• Sensor : InAs for better sensitivity

• Range : 0 - 20 Kg

• Indicate the direction of the magnetic field Power Supply : 230 V , 50Hz

• Hall probe Crystal : P- type lightly dopped

• Resistivity : 6 - 7 ohm.cm

• Thickness : 0.50 mm 2% 6.

• Travelling Microscope Optics : True achromatic objective with 75mm focusing distance and 10X Ramsden eyepiece with fine cross wire

• Scale: Horizontal scale : 20 cm divided at 0.5 mm interval

• Vertical scale : 14 cm divided at 0.5 mm interval

• Venire scale : 50 division with a least count of 0.01 mm

Experiments:

• Measurement of susceptibility of Ferric Chloride (Fecl3 ) Paramagnetic solution

• Measurement of susceptibility of Manganese Sulphate (MnSo) Paramagnetic solution
