Study of the variation in potential drop with length of wire by using a potentiometer (C.R.)

Order Code: 55710

Category: Physics Trainers

55710 Experimental Set Up has been designed specifically for Rthe study of variation in potential drop with length of wire by using a potentiometer. The set up is absolutely self contained and requires no other apparatus. Practical experience...



SPECIFICATION

55710 Experimental Set Up has been designed specifically for Rthe study of variation in potential drop with length of wire by using a potentiometer. The set up is absolutely self contained and requires no other apparatus.
Practical experience on this set up carries great educative value for Science and Engineering Students.

Object
  1. Study of the variation in potential drop with length of wire by using a Potentiometer.

Features
The Set up consists of the following :
  1. Potentiometer : 10 Wires, fitted with pulleys on Laminated Board, Piano type jockey with 10 contact points.
  2. D.C.Voltmeter, 65mm round dial, mounted on bakelite stand, to read 0-3V.
  3. 0-5V D.C. at 500mA, continuously variable regulated and short circuit protected Battery Eliminator.
  4. Weight : 6.7 Kg. (Approx.)
  5. Adequate no. of patch cords stackable from rear both ends 2mm spring loaded plug length ½ metre.
  6. Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
