Study of frequency of energy transfer as a function of coupling strength using Coupled Oscillator (C.R.)

Order Code: 55741

Category: Physics Trainers

  55741 Experimental Set Up has been designed specifically to study the frequency of energy transfer as a function of coupling strength using coupled oscillators. The set up is absolutely self contained and requires no other apparatus. Pr...



SPECIFICATION


55741 Experimental Set Up has been designed specifically to study the frequency of energy transfer as a function of coupling strength using coupled oscillators. The set up is absolutely self contained and requires no other apparatus.
Practical experience on this set up carries great educative  value  for  Science  and  Engineering Students.

OBJECT
  1. To study the frequency of energy transfer as a function of coupling strength using coupled oscillators.

FEATURES
The Set up consists of the following :
  1. Two Compound Pendulums. Each of these are essentially an aluminium rod of size 870mm approx., supported by two pin pivot arrangement on an aluminium stand. The centre of mass of the oscillatory system can be shifted by sliding masses above & below the pivot points.
  2. Coupling thread with various coupling loads of brass having one hanger 10gm and slotted weight of 10, 20, 20 & 50 gm one each.
  3. Double Convex lens dia 50mm F.L. 20cm.
  4. Filament bulb on an adjustable stand.
  5. Square paper screen size 8"x10" for lissajous figures on an adjustable stand.
  6. Bras Pin 4mm 1½ x 4mm, Brass Weight 2½ x 1½ and Brass Weight 1½ x 1.
  7. Digital Stop Clock with START/STOP operation by means of toggle switch & RESET by a push button switch. It has a range of 999.9 seconds with resolution of 0.1 seconds and accuracy of ±0.01% (Quartz controlled). Display is thorough 4 no’s of 12.5mm bright Seven Segment Displays and working voltage of the unit is 230V± 10% 50Hz.
  8. Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
