Silent Features:

• Fully Automatic operational Design
• Compact design and rugged construction ensures long service life and facilitates easy transport for field applications.
• Touch screen display
• Opto-electronically depth detection & measurement through imported Opto-electronic sensor
• Automatically timed programmable penetration measurements ? Preset penetration time at factory (Operator can also enter the user defined penetration interval through touch screen)
• Motorized placement of penetrator on sample surface
• Penetrometer arm automatically comes back to its home position at the end of 5 seconds penetration test
• In?built Facility to tare and reset the measurement results
• Display resolution of penetration depth in tenths of units (0.01mm)
• Magnifying lens for adjusting needle tip/cone tip exactly on the sample surface
• Low voltage Illuminator mounted on flexible arms to assist an operator during testing
• Built?in spirit level and leveling screws to ensure proper alignment
• Micrometer differential gearing mechanism for fine movement of head
• Weight of the Needle/Cone and plunger match the criteria of ASTM and IP requirements.
• The base of the instrument is also user adjustable ? It can be lifted up or down with the jack provided at the bottom.
• The penetration time is controlled and indicated on Digital LCD display with least count of 0.1 second.
• The Opto-electronic sensor installed within the instrument detects the penetration depth in 10th of millimeter (0.01mm)
• The penetration value is measured and indicated on digital LCD display
• Supplied complete with Needle/cone, container and applicable weight

Supplied complete with following Accessories in case of Bitumen penetration:

• Weight of 50 Grams   1 No.
• Penetration cup of 55mm diameter x 35mm height  1 No.
• Transfer dish  1 No.
• Penetrometer Needle  1 No.
• Needle Holder 47.5g ± 0.05g   1 No.
• Thermometer ASTM 17C (+19 to 27 °C)  1 No.

Supplied complete with following Accessories in case of Grease penetration:

• Sample container of 76.5mm dia x 63.5mm height  1 No
• Transfer dish   1 No
• Penetrometer Hollow 90° brass cone, Highly polished stainless steel tip   2 Nos

Technical specification
Measuring Range     :    0-40 mm
Timer Range             :    0-99,999 Seconds
Overall Dimensions  :    330 X 390 X 790(L X W X D) mm
Operation on            :    230 Volts, 50 Hz, Single Phase, AC Supply
