Split Air conditioning Trainer Board

Order Code: 24258345.3

Category: General Lab Equipment V

Technical Specification : Steel structure mounted on wheels, painted and treated in the oven Silk -screen- printed schematic diagram of the two alternative circuits, with warning LEDs 7000 BTU/h split-type unit with inverter, including vari...



SPECIFICATION

Technical Specification :

  • Steel structure mounted on wheels, painted and treated in the oven
  • Silk -screen- printed schematic diagram of the two alternative circuits, with warning LEDs
  • 7000 BTU/h split-type unit with inverter, including variable- speed hermetic compressor forced air condenser
  • 3-speed fan evaporator with deflector refrigerant expansion through capillary tube 4- way valve remote control for adjustment
  • On-offvalves
  • Valve for plant vacuum, refrigerant charging and recovering Full set of instruments for data acquisition, including:
  • Flow meters high and low pressure gauges 4 electronic thermometers with Pt100 probes to be inserted in various test points frequency-meter for measuring compressor r.p.m. Digital multimeter
  • High and low pressure switches
  • Thermomagnetic – earth leakage control button
  • Emergency button
  • Fault simulator via switches
  • Power supply :230Vac 50Hz single-phase-1500VA (Other voltage and frequency on request
  • Dimensions:180x80x180cm
