The instrument should have following features:

• Adjustment of entrance slit isprovided

• Prism table for accurate componentplacement

• Crosswire- Eyepiece

• Wideapertureoptics

• Rack and pinion arrangementfocusing

• Online product tutorials and manual should be available to perform lab experiments by following step-by-step experimental procedure.

Technical Specifications:
Base:

• Type Cast iron

• Circle dia : 150 mm. (6”)

• Scale Type : Stainless Steel

• Main scale : 0 - 360°

• Vernier scale : 30 div

• Least Count : 20”

• Collimator Tube length : 160mm.

• Focal length of Achromatic lens : 175mm (approx.)

• Telescope Tube length : 185 mm.

• Focal length of Achromatic lens: 175 mm. (approx.)

• Prism Geometry : 5050mm. equilateral

• Refractive index : 1.51

• Hollow prism : 5050mm.equilateral

• Plane transmission grating : 15,000 l/inch

• Light source : Mercury lamp

Experiments that can be performed:

• To determine the Wavelength of main spectral line of mercury light using plane transmission grating and spectrometer.

• To determine the Refracting Angle of prism using spectrometer.

• To determine the Refractive Index and Dispersive Power of prism using spectrometer.

• To determine the Refractive Index of transparent liquid like water using a hollow prism and spectrometer.

• To draw agraphbetween the Angleof Minimum Deviation and wavelength, for different colours of light using spectrometer.

• To plot a graph between Angle of Incidence and corresponding Angle of Deviation using prism and spectrometer.

• To draw a graph between the Refractive Index μ and Wavelength for different colour of light and to verify Cauchy's formula.
