Solar Tracker

Order Code: 55928

Category: Physics Trainers

55928 Understanding Solar Tracking System is a versatile training system for study and demonstration of Solar tracking. Solar tracker is a device which tracks the motion of the Sun, thus ensuring that the maximum amount of Sunlight strikes the pan...



SPECIFICATION

55928 Understanding Solar Tracking System is a versatile training system for study and demonstration of Solar tracking.

Solar tracker is a device which tracks the motion of the Sun, thus ensuring that the maximum amount of Sunlight strikes the panels throughout the day.

Features

  1. Complete training system to study the fundamentals of Solar Tracking
  2. Microcontroller based Tracking System
  3. Single-axis and Dual-axis Tracking
  4. Manual, Time and Auto Modes of operation in Single axis Solar Tracking
  5. Manual mode of operation in Dual-axis Solar Tracking
  6. Master Reset Switch for recovery of System
  7. Emergency Motor Stop Switches
  8. Tilt Sensors for sensing angle of panel with respect to horizontal plane
  9. Facility for charging battery using Solar energy as well as DC supply

Technical Specifications

  • Supply Voltage : 12V DC

Solar Panel

  • Maximum Output : 18W

Power (Pm)

  • Open Circuit : 21V DC

Voltage (Voc)

  • Short Circuit : 1.07A

Current (Isc)

  • Max. Output : 17V

Voltage (Vmp)

  • Max. Current (Im) : 1.06A
  • DC Motor : 12V
  • Rechargeable Battery : 12V, 7Ah
  • Display : 20 x 4 LCD
  • Light Sensor : Phototransistor
  • Acceleration/Vibration : +5V @ 1ma current
  • Fuse : 1Amp (3 Nos.)
  • DC Adaptor : 12V @ 1Amp
  • Dimension (mm) : W 350 x D 280 x H 55
