Shell and Tube Heat Exchanger

Order Code: 20214160PYAY.13

Category: General Lab Equipment III

Shell and Tube Heat Exchanger A thick-walled glass shell with 2 baffles contains cold water. which passes over 7 stainless steel tubes through which hot water flows. Tube bundle length of 205 mm giving a total heat transfer area of approxim...



SPECIFICATION

Shell and Tube Heat Exchanger

  • A thick-walled glass shell with 2 baffles contains cold water.
  • which passes over 7 stainless steel tubes through which hot water flows.
  • Tube bundle length of 205 mm giving a total heat transfer area of approximately 24000 mm2 Four thermocouples measure hot and cold fluid entry and exit temperatures.
  • Self-sealing quick-release connections enable rapid connection to and conversion from parallel to counter-current flow.
  • Requires the Heat Exchanger-Service Unit for operation.
