Sheet metal tools

Order Code: 22235575.4.67

Category: General Lab Equipment I

12no. Tool boxes  Function: for use in workshop Steel type, with two trays Handles & locking catch for pad lock. Approx size: 175x200x500mm Consisting of : 6no. Blow Lamps Function: for use in workshop Fu...



SPECIFICATION

  1. 12no. Tool boxes
    1. Function: for use in workshop
    2. Steel type, with two trays
    3. Handles & locking catch for pad lock.
    4. Approx size: 175x200x500mm
  2. Consisting of :
  3. 6no. Blow Lamps
    1. Function: for use in workshop
    2. Fuel: petrol or paraffin
    3. Capacity 0.75 to 1 litre
    4. Fitted with evercool handle
    5. Saftey devices
    6. Automatic cleaning needle
  4. 6no.Soldering Iron
    1. Function: for use in workshop
    2. Copper, non electric
    3. Straight with diamond tip
    4. Wooden handle, weight 450gr.
  5. 12no. Punch & Chisel Set
    1. Function: for use in workshop
    2. 12 piece set
    3. In wooden or metal holder
    4. Approx Specification:
      1. 1/4 inch cape chisel
      2. 5/16" cape chisel round nose
      3. 3/8" diamond point chisel
      4. 1/4" cold chisel
      5. center punch
      6. solid punch
      7. drift punch
      8. 5/8" cold chisel
      9. 1/8" pin punch
      10. 5/32" pin punch
  6. 12no. Tap & Die Set, Metric Small
    1. Function: for use in workshop
    2. HSS set of 7, circular split pattern
    3. To contain taper, 2nd, & bottoming taps, dies, die stocks & tap wrenches
    4. Supplied with fitted case
    5. Metric sizes: 6, 7, 8, 9, 10, 11 & 12mm
  7. 12no. Tap & Die Set, Metric Large
    1. Function: for use in workshop
    2. HSS, Set of 6, circular split pattern
    3. To contain taper, 2nd, & bottoming taps, dies, diestocks & tap wrenches
    4. Supplied in fitted case
    5. Metric sizes: 14, 16, 18, 20, 22 & 24mm
  8. 12no. Tap & Die Set, BSW
    1. Function: for use in workshop
    2. HSS, set of 7, circular split pattern
    3. To contain taper, 2nd & bottoming taps, dies, diestocks & tap wrenches
    4. Supplied in fitted case
    5. BSW sizes: 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4 inch BSW
  9. 12 no. Wing Divider
    1. Function: for use in workshop
    2. With wing & locking screw
    3. Fine polished
    4. Box jointed
    5. Suitable for all metal work
    6. 200mm long
  10. 12no.Protractor
    1. Function: for use in workshop
    2. 85mm diameter made of steel
    3. Graduated to 180 deg in both directions
  11. 3no. Universal Surface Gauge
    1. Function: for use in workshop
    2. Hardened steel base
    3. Surface ground with V-groove
    4. Spindle length 250mm
    5. With scriber, scriber clamp & spindle clamp.
  12. 6no. Plumb & Spirit Level
    1. Function: for use in workshop
    2. Made of aluminium
    3. With "rainbow" tubes 600mm. Riveter
    4. Function: general metalwork shop use.
    5. For all standard "pop" rivits 3 to 5mm
  13. 12no. Rivet Set-up Set
    1. Function: for use in workshop
    2. Made of hardened steel
    3. For drawing up rivits before closing
    4. In wooden stand
    5. Set of 5 pieces for 4, 6, 8, 10 & 12 mm rivit
