Screening Unit

Order Code: 32382

Category: Thermodynamics Lab

Features professional analyzer for 32371 Screening Unit 32382 enables users to separate a mixture of solids into several classes of particle sizes. In the screening process, each particle is compared with a screen mesh in terms of size and shape....



SPECIFICATION

Features
professional analyzer for 32371

Screening Unit 32382 enables users to separate a mixture of solids into several classes of particle sizes. In the screening process, each particle is compared with a screen mesh in terms of size and shape. Depending on their position, particles with an irregular shape may not be able to pass through the mesh. As the screening machine is vibrating, each particle has the possibility to pass through the meshes several times. First the coarser particles are separated in the upper area. The mesh width decreases towards the bottom. To be able to adapt
Technical Specifications
Ø of the screens: 200mm each
Height of the screens: 50mm each
Screening machine
Screening duration: 0…60min
Vibration height: 0…3mm
Mesh width of the screens
45μm
63μm
* 125μm
* 250μm
* 500μm
* 710μm
* 1000μm
the machine to the * 1250μm
respective requirements, several screens with various mesh widths are included in the scope of delivery. Scales enable the user to determine the masses of the separated classes in order to determine the particle size distribution.

Specifications
Screening machine for particle size analysis as accessory for 32371
Screening   duration   and   vibration   height adjustable
11 screens with different mesh widths
Scales for determining the mass fraction of the separated classes
* 1600μm
* 2000μm
* 4000μm
Scales
Max. weight: 2200g
Resolution: 10mg

Experiments
Determination of particle size distributions

Requirements
Mains Power 220 – 240V @ 50Hz, 1Ph
