Reaction turbine: Investigation of a compressed air driven radial reaction turbine.

Features

• characteristic behaviour of a reaction turbine with air flow, optimal view of the operating area of a turbine, load applied by band brake.

• Learning objectives/experiments, familiarisation with the design and function of an impulse turbine, determination of torque, power and efficiency, graphical representation of characteristic curves for torque, power and efficiency.

Specification

• investigation of a compressed air driven radial reaction turbine

• transparent housing for observing the operating area

• rotor with 4 outlet nozzles

• application of load to the turbine by means of a band brake

• setting of the primary pressure with the pressure reducing valve

• valve and flow meter for setting the flow

• solenoid valve as a safety device to prevent overspeed

• determination of the torque on the turbine shaft using a force sensor

• measurement of the turbine speed with an optical speed sensor

• manometer for displaying the pressure on the inlet and outlet side

• digital display of speed, torque and temperature.

• Technical data: Reaction turbine, max. power: 20W at 19000min-1. Rotor,

• diameter: 55mm,4 outlet nozzles, diameter: 1,5mm.

• Measuring ranges-temperature: -20...1100°C, speed: 0...30000min-1, torque: 0...10Ncm, flow rate: 25...315L/min,

• inlet pressure: 0...2,5bar,

• outlet pressure: 0...0,1bar, primary pressure:0 -10bar,230V, 50Hz, 1 phase
