Product Description:
In today’s rapidly advancing automation landscape, the role of PLC (Programmable Logic Controller) has become increasingly significant. This HMI PLC Platform is an ideal setup for learning about the working principles of PLCs and HMIs (Human Machine Interfaces) used in industrial applications.

With this platform, students can gain hands-on experience and practice the following:

• Wiring of PLC with different types of inputs and outputs
• Connecting various inputs such as Push-to-ON switch, Toggle switch, Limit switch, and IR Sensor to the PLC
• Realistic simulations to drive visual indicators, audio indicators, DC motors, pilot lamps, and relay cards
• PLC communication with Human Machine Interface (HMI) for monitoring and controlling

Product Features:

• 7-inch Human Machine Interface (HMI)
• PLC with 8 Digital Inputs and 8 Digital Outputs
• Open platform for exploring a wide range of PLC applications
• RS485 Communication interface for PLC and HMI integration
• Industrial-grade design with a realistic look and feel
• Inputs include Toggle switches, Push-to-ON switch, Limit switch, IR Sensor, LEDs, Buzzer, DC Motor, Pilot Lamp, and Relay card
• PC-based Ladder Programming and HMI programming
• Easy-to-use, student-friendly software for program development
• Powerful instruction sets for robust programming capabilities
• Din rail mounting for PLC for industrial-level setup
• High-speed execution
• Several pre-programmed sample Ladder programs for practice
• Options for PLCs and expansion modules
• Easy program downloading
• Troubleshooting practice
• Compact, ergonomic, tabletop design
• Ready-to-use experimental details
• Sturdy and durable construction

Warranty & Services:

• Warranty: 2 years, including service and spare parts
• Installation, Testing, and Commissioning: To be performed by expert engineers
• Training: A 5-day training session at the point of delivery, provided to at least five participants
• Experiment Manual: A detailed manual with step-by-step instructions for each experiment will be provided
