Power electronics trainer (Modular)
Order Code: 24257587.7
Category: General Lab Equipment V
Power Supplies: Fixed AC Supply: 18V-0V-18Vand Output Voltage: 12V-0V-12V on one device. Output Voltage: 18V-0V-18V Output Voltage: 0V-36V Output Voltage: 12V-0V-12V Output Voltage: 0V-24V Output...
SPECIFICATION
Power Supplies:
-
Fixed AC Supply: 18V-0V-18Vand Output Voltage: 12V-0V-12V on one device.
-
Output Voltage: 18V-0V-18V
-
Output Voltage: 0V-36V
-
Output Voltage: 12V-0V-12V
-
Output Voltage: 0V-24V
-
Output Voltage: 0V-220V
Fixed DC Supply
-
DCV Output Voltage: +12V, -12V
-
DCV Output Voltage: +5V
Digital Voltmeter:
-
DC Voltage Range: 200mV, 2V, 20V, 200V(1000V)
-
AC Voltage Range: 0V ~ 600V
Digital Ammeter:
-
DC Current Range: 200mV, 2V, 20V, 200V
-
AC Current Range: 0V ~ 400V(1000v)
Components mounted on the panels:
-
SCR Assembly: 6 SCR, 600V, 2A
-
MOSFET Assembly: 6 MOSFET
-
Power Devices:
-
IGBT, MOSFET and UJT
-
DIAC, TRIAC and SCR
-
Power Transistor
-
Power Diode 8A
Capacitors on Board:
Inductors on Board:
Resistance on Board:
Potentiometer:
Load:
-
Lamp
-
DC Motor 12V
Firing Circuit on Board:
-
Line Synchronization Firing Control Circuit.
-
PWM Firing Control Circuit (Frequency Control).
-
Triac Firing Control Circuit
One Teacher and Student Manual with all the possible experiments
