Portable Watt/VAR/ Power Factor Meters

Order Code: 23246961.31

Category: General Lab Equipment III

Portable Type instruments are Electrodynamometer type instruments. They can be used in Single Phase, Three Phase Three wire and Three Phase Four wire systems, and are designed to be used in horizontal positions. Electrodynamometer Type Meters &...



SPECIFICATION

Portable Type instruments are Electrodynamometer type instruments. They can be used in Single Phase, Three Phase Three wire and Three Phase Four wire systems, and are designed to be used in horizontal positions.

Electrodynamometer Type Meters



Rated Accuracy  : ± 1.0% of full scale value as per ISS 1248/84 between 10% to 100% of the scale for Single phase UPF Wattmeters
                             : ± 1.5% of full scale value as per ISS 1248/84 for Three Phase Wattmeters
                             :  ± 1.5% of full scale value as per ISS 1248/84 for 0.2 P.F. (LPF) Single Phase Wattmeter
                             : ± 3° (Electrical) as per ISS 1248 for Power Factor Meters
Note                     : All Wattmeters are calibrated at cos f = 1 and Varmeters at sin f = 1
                             : All Low Power Factor Watt meters are calibrated at cos f = 0.2 lag
                             : Other voltage and current ranges can be supplied on request, subject to technical feasibility



Order Code Load Current Coil Potential Coil
Wattmeters   Choose One Choose One
20015 Single Phase

1/2A, 2.5/5A, 5/10A 10/20A, 15/30A

50/100V, 75/150V, 125/250V 150/300V, 250/500V, 300/600V
