Polarisation of light by simple reflection using Laser (C.R.)

Order Code: 55812

Category: Physics Trainers

  55812 Experimental Set-Up has been designed specifically to study the Polarisation of Light by Simple reflection using Laser. The set-up consists of Circular table, Diode Laser, Glass Slab, Analyser attachment with Laser Detector,Nanoammete...



SPECIFICATION


55812 Experimental Set-Up has been designed specifically to study the Polarisation of Light by Simple reflection using Laser. The set-up consists of Circular table, Diode Laser, Glass Slab, Analyser attachment with Laser Detector,Nanoammeter, Reading lens and Spirit Level.
The set-up is complete in all respect and requires no other apparatus. Practical experience on this set-up carries great educative value for Science and Engineering Students.

OBJECT
  1. To study Polarisation of light by simple reflection using Laser.

FEATURES
The complete Experimental Set-up consists of the following items.
  1. He-Ne Laser with Power Supply. on heavy duty stand
    • Maximum output : 1 mW
    • Wave length : 670 nm visible red
    • Power supply : Included with ON/OFF switch working on 230 mains.
  2. Circular Table : Spectrometer scale 6” dia circle with vernier but without Collimator & Telescope. It has one holders for Laser Detector.
  3. Analyser attachment : Fitted with circular scale graduated in 360° with Laser Detector
  4. Glass Slab : Size 75 x 50 x 18 mm
  5. Digital Microammeter : micro ammeter 0–200 uA. DC house in bakelite case, display 3½ digit, power required 230V ±10% at 50 Hz. mains.
  6. Reading Lens : 50 mm diameter with handle
  7. Spirit Level : 60 mm length
  8. Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
