PLC trainer Kit

Order Code: 21224710.1.2

Category: General Lab Equipment III

The training system enables the trainee to use original parts for industrial applications. All components comply with the relevant DIN regulations. The PLC used should comply with the SIMATIC S7-1500 standard or a comparable product. Action-oriented ...



SPECIFICATION

The training system enables the trainee to use original parts for industrial applications. All components comply with the relevant DIN regulations. The PLC used should comply with the SIMATIC S7-1500 standard or a comparable product. Action-oriented teaching materials support the trainer and trainees in the training of PLC contents, they contain at least:


 Training board with industrial components; the boards can be mounted in a holding frame on the laboratory bench (see item Hydraulik Pneumatic 5).

  •  PLC software and simulator
  •  Interface SPS with system
  •  Commissioning of a PLC
  •  Application criteria for mechanical, optical, capacitive and inductive proximity switches
  •  Sequence control and parallel logic
  •  Systematic programming of a PLC according to the international standard IEC 1131-3
  •  IEC 1131-3 programming languages: Function diagram, ladder diagram, instruction list, structured text and sequential function chart
  •  Design and testing of PLC configurations
  •  Implementation of industrial automation with PLC
  •  Troubleshooting with the PLC
  •  The Teachware contains exercises and descriptions for all content mentioned here (table of contents and example task attached to the offer).
  •  The delivery should also be included:
  • 1 PLC trainer with PLC-CPU
  • 1 programming software on USB stick
  • 1 programming cable
  • 1 power supply unit international 230 V AC / 24 V DC
  • 1 remote control
