Multi Vibrator

Order Code: 22236220.1.18

Category: General Lab Equipment I

Monostable (one-shot) or a stable (free-running) operation True and complemented buffered outputs Only one external resistor and capacitor required Monostable multivibrator Positive- or negative-edge triggering Output pulse width indepen...



SPECIFICATION

  • Monostable (one-shot) or a stable (free-running) operation True and complemented buffered outputs
  • Only one external resistor and capacitor required
  • Monostable multivibrator
    • Positive- or negative-edge triggering Output pulse width independent of trigger pulse duration
    • Retriggerable option for pulse-width expansion Long pulse width possible using small RC components with external counter provision
    • Fast recovery time independent of pulse width Pulse-width accuracy maintained at duty cycles approaching 100%
  • Astable multivibrator
    • Free-running or gatable operating modes 50% duty cycle
    • Oscillator output available VDD supply voltage 315V, VI input voltage 0 VDD V Tamb ambient temperature in free air- 40+85 °C, VDD = 5 V-3.75 us/V, VDD = 10 V -0.5μs/V
    • At/AV input transition rise and fall rate VDD = 15 V -0.08 us/V
