Multi Output Power Supply
Order Code: 24257624.33
Category: General Lab Equipment V
1. Output Channels Channel 1: 0 – 30V / 2A (Variable) Channel 2: 0 – ±15V / 1A (Tracking) Channel 3: 4.5V to 5V / 5A (Fixed) 2. Setting Resolution Voltage: 10 mV Current: 5 mA ...
SPECIFICATION
1. Output Channels
-
Channel 1: 0 – 30V / 2A (Variable)
-
Channel 2: 0 – ±15V / 1A (Tracking)
-
Channel 3: 4.5V to 5V / 5A (Fixed)
2. Setting Resolution
-
Voltage: 10 mV
-
Current: 5 mA
3. Mode of Operation
-
Constant Voltage (CV)
-
Constant Current (CC)
4. Regulation
-
Load Regulation (CV Mode): < 0.05% + 10 mV
-
Line Regulation (CV Mode): < 0.05% + 10 mV
5. Ripple & Noise
-
≤ 1 mVrms (CV Mode)
6. Recovery Time
-
≤ 50 μs
7. Current Limit Adjustment
-
Adjustable from 100 mA up to maximum rated current
8. Display
-
3-digit seven-segment LED display for voltage and current
-
Switchable display for all three output channels
9. Display Accuracy
-
Voltage: ±(1% + 1 digit)
-
Current: ±(1% + 3 digits)
10. Protection Features
-
Overload protection
-
Short circuit protection
11. Input Supply
-
230 VAC ±10%, 50 Hz
12. Operating Conditions
-
Temperature Range: 0°C to 50°C
-
Relative Humidity: ≤ 95%
