Multi meter (Digital)

Order Code: 23247243.2

Category: General Lab Equipment IV

Technical Specifications: 3 3/4 True RMS multimeter DCV range: 400m/4/40/400V, 1000V ACV range: 400mV, 4/40/400/750V DCA range: 400u/4000uA, 40m/400mA, 10A ACA range: 400u/4000u/40m/400mA, 10A Resistance: 400Ω, 4k/40k/400k/4M&Om...



SPECIFICATION

Technical Specifications:

  • 3 3/4 True RMS multimeter
  • DCV range: 400m/4/40/400V, 1000V
  • ACV range: 400mV, 4/40/400/750V
  • DCA range: 400u/4000uA, 40m/400mA, 10A
  • ACA range: 400u/4000u/40m/400mA, 10A
  • Resistance: 400Ω, 4k/40k/400k/4MΩ, 40MΩ
  • Capacitance: 10n, 100n/1u/10u/100uF, 1/10/100mF
  • Frequency: 100/1000/10k/100kHz, 1M/30MHz
  • Temperature: -20~400°C, 400~1000°C
  • Continuity with beeper
  • Diode & transistor test facility
  • Data hold & auto power-off function
  • LCD backlight and low battery indication
  • Safety Standard: CAT IV 600V
  • Power: 9V battery
  • Accessories: Test lead, Transistor test socket, Thermocouple probe and operation manual
  • Warranty: 1(One) year with services
  • Documents: Catalogue should be submitted
