• Magnification Range: 50x to 1000x

• Observation Head:

  • Trinocular head inclined at 45°

  • 360° rotatable

  • Interpupillary and diopter adjustment provided

• Stand: Heavy-duty, rigid construction for stability

• Focusing Mechanism:

  • Separate coarse and fine focus knobs

  • Fine focus graduation: 0.002 mm per division

• Mechanical Stage:

  • Size: 120 mm x 140 mm

  • Movement range: 50 mm x 70 mm

  • Vernier graduations for precise slide positioning

  • Co-axial control for convenient slide manipulation

• Illumination:

  • Built-in 3W LED lamp with adjustable brightness

• Condenser:

  • Sub-stage Abbe condenser N.A. 1.25 with iris diaphragm

  • Swing-out filter holder

  • Rack and pinion focusing mechanism

• Nosepiece:

  • Quadruple revolving nosepiece with positive click stops

• Objectives:

  • Achromatic 5x, 10x, 45x, and 100x oil immersion (SL)

• Eyepieces:

  • Wide Field 10x (anti-fungus coated)

  • Field of View (FOV): 18 mm

Digital USB Camera Specifications:

• Resolution: 5.0 Megapixels (2592 x 1944)

• Sensor Type: Color CMOS, 1/2" size

• Pixel Size: 2.2 µm x 2.2 µm

• Color Depth: 30-bit

• Exposure Time Range: 1 microsecond to 2 seconds

• Interface: USB – Plug and play with PC

• Features:

  • Captures high-quality images and transmits digital signals directly to a computer

  • Compatible with standard microscopes

  • Ideal for research, documentation, and teaching applications
