Impulse Turbine
Order Code: 32028
Category: Fluid Mechanics Lab
Features: Model of a Impulse Turbine Transparent Operating Area Technical Description: Typical for Impulse Turbines is the conversion of pressure into kinetic energy in a distributor. The Turbines consists of the Impulse wheel, an adjustable n...
SPECIFICATION
Features:
Model of a Impulse Turbine
Transparent Operating Area
Technical Description:
Typical for Impulse Turbines is the conversion of pressure into kinetic energy in a distributor.
The Turbines consists of the Impulse wheel, an adjustable needle jet as the distributor and the housing (transparent on one side). The turbine is loaded with a braking band. In addition, the water pressure can also be measured with the manometer located on the unit.
Experiments:
1. Determination of typical turbine curves
Specifications:
Functional Model of a Impulse Turbine
I x w x h : 400 x 400 x 620mm, Weight 12kg
Technical Data:
Turbine : Power Output approx. 5.6W (at V ≈ 30.7Ltr/min, H = 2m, n = 500rpm) Impeller : External Diameter 132mm, Width of vane 33.5mm, 14vanes
Nozzles : Diameter of stream 10mm
Dimensions and Weight
I x w x h : 400 x 400 x 620mm Weight : approx. 12kg
Scope of Delivery
Turbine with Braking Device, completely assembled on base plate
Instruction Manual
