Hydrostatic Pressure On Submerged Surfaces Trainer
Order Code: 24258098.20HYDROSTAT
Category: General Lab Equipment V
HYDROSTATIC PRESSURE ON SUBMERGED SURFACES TRAINER: Investigation of fluid pressure on vessel walls. Features- determination of forces on surfaces under hydrostatic pressure. Learning objectives/ experiment, -pressure distribution along ...
SPECIFICATION
HYDROSTATIC PRESSURE ON SUBMERGED SURFACES TRAINER: Investigation of fluid pressure on vessel walls.
Features- determination of forces on surfaces under hydrostatic pressure. Learning objectives/ experiment, -pressure distribution along an effective area in a liquid at rest,-lateral force of the hydrostatic pressure,- determination of the centre of pressure and centre of area,- determination of the resulting compressive force.
Specification
-
investigation of the hydrostatic pressure in fluids at rest
-
tiltable water tank with fill level scale
-
lever arm with different weights.
-
Technical data: Water tank,- inclination angle: 0°...90°,-
-
content: 0...1,8L,- scale: 0...250mm,- effective area, max. 75x100mm. Lever arm,- max.
-
length: 250mm.
-
Weights- 1x 2,5N,- 1x 2N,- 2x 1N,- 1x 0,5N
