Guillotine Shears (Up To Gauge 16)

Order Code: 22235575.1.108

Category: General Lab Equipment I

Use: cutting heavy gauge sheet metals, motor  Driven Motor driven plate guillotine shear with a cutting capacity of max. 4.0mm sheet thickness (related to 3200 mm working length). Computer optimized welded steel design of shear mach...



SPECIFICATION

Use: cutting heavy gauge sheet metals, motor

  1. Driven Motor driven plate guillotine shear with a cutting capacity of max. 4.0mm sheet thickness (related to 3200 mm working length).
  2. Computer optimized welded steel design of shear machine frame. The cutting bar driven by crank drive and a noiseless gear motor on each side of the machine.
  3. Along the machine table there are sheet support covers of stainless steel with a snap lock system. Between the sheet support covers
  4. there adjustable front support arms with Tslots, 1000 mm scales and gauge fingers for easy front gauging.
  5. On each side of the cutting table there are rectangular gauges with stainless steel scales of 1000 mm. During the cut a mechanical hold-down bar with non-skid ebonite lining holds the part.
  6. All bearings and guide ways are maintenance free.
  7. Upper and lower blades consist of high-quality steel with two edges.
