Technical Specification:

• Operation Mode: Full-Automatic Control
• Air Pressure: Min. 6 bar
• Air Consumption: Min. 20 m³/hr
• Max. Power Consumption: 5 kWh
• Heating: 0.4-0.8 MPa
• Max. Bending Thickness: 1.0 mm
• Max. Bending Length: 2520 mm
• Min. Packing Size: 3300 x 760 x 1400 mm
• Bending Angle: 0° to 135°
• Cylinder: Stainless Steel
• Heating Source: Electric and Steam
• Used In: Hospital, Textile
• Display & Control: LCD Display and Intelligent Control Systems
• Min. Folding Speed: 50 m/min
• Channel's Quantity: Multiple
• Structure: Horizontal

Power Requirement:

• 230V or 380VAC/50Hz + N + G

Working Environment:

• Operating Temperature Range: +5°C to +40°C
• Relative Humidity: <85%

Regulatory Requirements:

• Quality Management System Certification: ISO 9001:2015 (issued by a Conformity Assessment Body, Notified or Accredited body, or recognized by the International Accreditation Forum (IAF))
• Certificates and Declaration of Conformity (DOC): Compliance with EU/EN 2006/42/EC (Machinery) and 2014/30/EU (Electromagnetic Compatibility)
• Market Authorization or Approval: By one of the Global Harmonization Task Force (GHTF) founding members (US, EU, Canada, Japan, Australia)

Conformity to Safety and Performance Standards:

• Certificate of Compliance: EN 61010-1 Category IV, 600V, rated to IP65 (dust-tight and protected against jets of water)

Configuration:

• Calibrated and configured to the standard at the manufacturing location

Software:

• Appropriate software to run the device and license (if applicable) included

Scope of Supply:

• Manufacturer’s Standard Scope of Supply (includes all accessories)

Documentation:

• All documentation (product datasheet, brochures, certificates of compliance, operating and maintenance manuals, etc.) must be supplied in English, including:
  • User Manual
  • DQ/QC Instrument Compliance Test Certificate
  • IQ Documentation
  • OQ Documentation
  • Instrument Logbook
  • Compliance Certificates for Tools

Accessories:

• All necessary accessories and software for long-term operation of the machine

Training, Installation, Testing, and Commissioning:

• Comprehensive on-site training and certification for engineers and technicians, covering installation, testing, commissioning, operation, and maintenance, ensuring full qualification to handle, operate, and maintain the machines in compliance with safety and performance standards
