Flapper Nozzle Assembly

Order Code: 52270

Category: Process Control Trainers

Features Compact Ergonomic Design. User Friendly, Self Explanatory Systems. Robust Construction. MS powder coated frame. Training Manuals for Operation Ease. Inbuilt Safety Measures to avoid improper usage Experiments To ...



SPECIFICATION

Features

  1. Compact Ergonomic Design.
  2. User Friendly, Self Explanatory Systems.
  3. Robust Construction.
  4. MS powder coated frame.
  5. Training Manuals for Operation Ease.
  6. Inbuilt Safety Measures to avoid improper usage


Experiments

  1. To plot the characteristics of Displacement (micron) Vs Pressure (Psi).


System Components

  1. Flapper Assembly.
  2. Nozzle Assembly.
  3. Micrometer for application of linear displacement to Flapper.
  4. Air Pressure Regulator.
  5. Pressure gauge for backpressure measurement.


Services Required

  1. Clean, Dry Compressed Air Supply at 2.1 Kg/cm².
