Basic Electro-Pneumatic Training Set -The set consists of the following items:

1. Relay, 3-fold-2 unit
2. Power: 24 VDC
3. Contact: 4
4. Contact load: max. 5 A
5. Allowed load: max 90 W
6. Response time: 10 ms
7. Block time: 8 ms
8. Push button switch set-1 unit
9. Power: 24 VDC
10. 2 momentarily, 1 locking
11. Contact: 2 open, 2 closed
12. Contact allowed load: Max. 1 A
13. Power consumption: 0.48 W
14. Pilot lamp and buzzer unit-1 unit
15. Power: 24 VDC
16. Lamp power consumption: 1.2 W
17. Buzzer power consumption: 0.04 W
18. Buzzer frequency : 420 W
19. Electric proximity switch-1 unit
20. Power : 24 VDC
21. Switching capacity : Max 10 W
22. Operating current : 50 mA
23. Switching frequency: Max. 800 Hz
24. 3/2-way single solenoid valve-1 unit
25. Pressure range : 0.5 – 9.8 bar
26. Response time : 20 ms
27. Normally closed
28. Return : spring
29. LED and protection circuit
30. 5/2-way single solenoid valve-2 unit
31. Pressure range : 0.5 – 9.8 bar
32. Response time : 20 ms
33. Return : spring + pilot
34. LED and protection circuit
35. 5/2-way double solenoid valve-2 unit
36. Pressure range : 0.5 – 9.8 bar
37. Response time : 20 ms
38. LED and protection circuit
39. 5/3-way double solenoid valve (All block)-1 unit
40. Pressure range : 0.5 – 9.8 bar
41. Response time : 20 ms
42. LED and protection circuit
43. Pressure sensor with display / Pressure switch-1 unit
44. Pressure range : -0.105 – 1.05 MPa
45. Adjustable pressure
46. Pressure digital display
47. Electrical limit switch, left actuation-2 unit
48. Contact : 24 VDC, 5 A
49. Contact : 1c
50. Switching frequency : max 200 Hz
51. Roller lever switch
52. Electrical limit switch, right actuation-2 unit
53. Contact : 24 VDC, 5 A
54. Contact : 1c
55. Switching frequency : max 200 Hz
56. Roller lever switch
57. Power supply unit-1 unit
58. Power : AC 230 V
59. Output power : 24 VDC
60. Output current : 4.5 A
61. Short circuit protection
62. Set of electrical cables
63. Red: 1500mm–1ea, 1000mm–2ea,
64. 600mm–22ea, 300mm–28ea, 100mm-10ea
65. Blue: 1500mm–1ea, 1000mm–2ea,
66. 600mm–12ea, 300mm–10ea, 100mm-10ea
67. High elasticity and special coating
68. Textbook – Electro-Pneumatics English
69. Workbook – Basic Electro Pneumatics English
70. Training at site for 2 days
71. Warranty- 2 years warranty against manufacturing defects
