Electro Pneumatic Compact Trainer With PLC

Order Code: 52107A

Category: Pneumatic Trainers

Product List  Electro Pneumatic Compact trainer kit with PLC 1 Nos Junction box with slide valve 1 Nos FRCLM with pressure gauge 1 Nos Miniature Single acting cylinder - Magnetic(Ø25x50) 1 Nos Miniature double acting cylind...



SPECIFICATION

Product List
Electro Pneumatic Compact trainer kit with PLC 1 Nos
  1. Junction box with slide valve 1 Nos
  2. FRCLM with pressure gauge 1 Nos
  3. Miniature Single acting cylinder - Magnetic(Ø25x50) 1 Nos
  4. Miniature double acting cylinder(Ø25 x 100) 1 Nos
  5. Double foot mounting (Ø25) 2 Nos
  6. 5/2 Way Double solenoid pilot operated valve 1 Nos
  7. 3/2 Way NC Single sol. pilot operated valve with sp. return 1 Nos
  8. Inline flow control valve 3 Nos
  9. Union TEE fittings 2 Nos
  10. Dummy Plug 2 Nos
  11. Union Y Fittings 2 Nos
  12. Ø4 PU tube 10 Mtr
  13. Ø8 PU tube 0.5 Mtr
  14. Tube cutter 1 Nos
  15. Electrical Push Button Assy 1 Nos
  16. Magnetic Sensor with clamp for Miniature DAC Cylinder 4 Nos
  17. Electrical connection set-banana plugs and cables 1 Nos
  18. PLC Assembly 1 Nos
  19. Panel 1 Nos

Switch mode power supply
Technical specifications
  • Size (in mm) : 190x140x60
  • No. of output : 1
  • Input Voltage : 85 264 V AC, 47 63 Hz
  • Output Voltage : 24V DC, 4A
  • Power cord : 3Pin , Type M
  • Protection : AC - 2A glass type fast blown fuse
  • DC - 4A glass type fast blown fuse
  • Material : ABS
