Electrical Basic Principle Trainer

Order Code: 46978

Category: Electrical Machine Lab

46978 Electrical principle panel Is a teaching system that covers the fundamentals of teaching electrical power in dc, single-phase and three-phase circuits and systems.   We provide a step-by-step guide for setting up and carrying out eit...



SPECIFICATION

46978 Electrical principle panel Is a teaching system that covers the fundamentals of teaching electrical power in dc, single-phase and three-phase circuits and systems.



We provide a step-by-step guide for setting up and carrying out either systems assignments.



We provide a step-by-step guide for setting up and carrying out either systems assignments.



Curriculum cover Ohms rule, series and parallel circuits, resistance, reaction and impedance, phase relationships, balance loads, and dc & ac power .



All modules fit into a bench-standing frame designed for purpose and can be slotted in and out as needed.



During the development of this system safety was of paramount importance and every effort was made to protect both the user and the equipment. Safety 4 mm sockets are used for connections
