Dumpy Level And Its Accessories

Order Code: 23246574.1

Category: General Lab Equipment II

(Tripod, Staff reading, Plumb bob)Image : erect - Magnification: 32X Effective - Object aperture: 42mm - Field of view: 1` 20`` - Minimum focus: 0.40 m - Multiplication constant: 100 - Additive constant : 0 - Compensator range: + or -15 - Com...



SPECIFICATION

(Tripod, Staff reading, Plumb bob)Image : erect
- Magnification: 32X Effective
- Object aperture: 42mm
- Field of view: 1` 20``
- Minimum focus: 0.40 m
- Multiplication constant: 100
- Additive constant : 0
- Compensator range: + or -15
- Compensator setting accuracy : +or-0.3``
- Sensitivity of bubble: 10`/2mm
- Double run leveling : 1mm
- Net weight: 1.85kg
- Center screw type: M16&5/8
