Ductless Fumehood

Order Code: 22236125.7

Category: General Lab Equipment II

Ductless fumehood includung activated carbon filter Specifications Max External size (WxDxH) (mm): 1840x800x2200 Max Internal size (WxDxH) (mm): 1620x670x730 Max Opening: 500mm Air Velocity: 0.3~0.8m/s Noise: ≤60dB (A) Exhaust D...



SPECIFICATION

Ductless fumehood includung activated carbon filter

Specifications

  • Max External size (WxDxH) (mm): 1840x800x2200
  • Max Internal size (WxDxH) (mm): 1620x670x730
  • Max Opening: 500mm
  • Air Velocity: 0.3~0.8m/s
  • Noise: ≤60dB (A)
  • Exhaust Duct: PVC
  • Standard length: 4 meters
  • Standard diameter: Ø300mm
  • LED Lamp: at least 36W
  • UV Lamp: Shall have emission of 253.7 nanometers for most efficient decontamination
  • Equipped with LED Display and Water & Gas remote control
  • Blower: Built-in centrifugal blower; Speed adjustable
  • Front Window: 5mm toughened glass; Motorized; Height adjustable
  • Power Supply: AC220V±10%, 50/60Hz
  • Material: Exterior: Cold-rolled steel with anti-bacteria powder coating, Interior: High grade melamine board with good acid and alkali resistance function Work Table: Phenolic resin
  • The Standard Accessories: UV lampx2, Fluorescent lamp, Water tap, Gas tap, Water sink, Base cabinet, Total load of 2 waterproof sockets: 500W, 4m PVC exhaust duct, pipe strap and Active carbon filter

Installation

  • Installation of equipment provided by a trained engineer( enginer with experience in installation and maitainance of  laboratory equipment)
