Digital to Analog Converter
Order Code: 38715
Category: Digital Electronics Trainers
38715 Digital to Analog Converter composed of devices that transform a digital word into analog signal. The Digital to Analog Converter 3815 demo-nstrates three techniques : 4 bit weighted resistor discrete D/A Converter 4 bit R-2R ladde...
SPECIFICATION
38715 Digital to Analog Converter composed of devices that transform a digital word into analog signal. The Digital to Analog Converter 3815 demo-nstrates three techniques :
- 4 bit weighted resistor discrete D/A Converter
- 4 bit R-2R ladder discrete D/A Converter
- 8 bit monolithic D/A Converter
Features
- Self contained Scientech 2602
- Discrete & monolithic D/A conversion
- On board Function Generator & Counter
- Functional blocks indicated on board mimics
- Online Product Tutorial
- Built in DC Power Supply
- Compact size
Object
- Functional verification of weighted resistor D/A Converter
- Record the transfer characteristics of weighted resistor D/A Converter
- Functional verification of D/A Converter with ladder network
- Record of transfer characteristic of the ladder network D/A Converter
- Functional verification of an integrated D/A Converter
Technical Specifications
D/A Conversion : 2.4 bit R-2R ladder network
: 1.4 bit weighted resistor
: 3.8 bit monolithic D/A Converter
Signal Source : DC Supply with toggle switches
O/P Indication : On DMM or Oscilloscope
Interconnections : 2mm banana sockets
Power Supply : 110-220 V ±10%, 50/60 Hz
Dimensions (mm) : W 326 x D 252 x H 52
Weight : 2 Kgs approximately
Included Accessories
Patch cord 16” (2mm) : 17 nos.
Mains cord : 1 no.
