Digital Hydraulic Bench

Order Code: 24258341.1

Category: General Lab Equipment V

Experiments Features: Electronic flowmeter and digital display for accurate measurements and quicker experiments Should be made of lightweight fiberglass for strength, easier transport and long life Should have lockable wheels for mobility w...



SPECIFICATION

  • Experiments Features:
  • Electronic flowmeter and digital display for accurate measurements and quicker experiments
  • Should be made of lightweight fiberglass for strength, easier transport and long life
  • Should have lockable wheels for mobility with stability and flat top to hold different experiment modules
  • Self-contained with re-circulating water circuit
  • Should not need any external water supply to save mains water Description:
  • The body of the bench should form a reservoir or Sump Tank with a submersible pump
  • Should have a rim around the top to contain any spilled or excess water
  • A small recess or Trough in the top should work with a removable drain valve to trap a small volume of water
  • It should also catch discharged water from some experiments in the fluid mechanics range
  • A hand-operated control valve should adjust the water flow rate from the pump
  • An electrical box on the side of the bench should include the pump switch, circuit protection and a digital display of flow
  • A sight gauge to the lower side of the bench should allow the user to check the water level inside the tank
  • An electronic flowmeter should measure the outlet flow from the submersible pump and the signal from the flowmeter should pass to the digital display to show the flow rate
  • Technical Parameters:
  • Sump tank capacity: 100 Litres minimum and 160 litres maximum
  • Maximum flow: Min. 50 litres/minute with no experiment module fitted
  • Maximum pressure: 450 mbar at working surface height
  • Flowmeter display: L.s- 1 and L.min-1
  • Resolution: 0.001 L.s-1 and 0.1 L.min-1
  • Power source: 220~230V AC, 50Hz, 1 Phase
  • Required Accessories: Water additive, datasheet, all necessary pipes, pipe clips and Printed operation manual
  • Warranty: 1 (One) year with services
