Design & Tech lab table

Order Code: 24257288.12

Category: General Lab Equipment V

Design and Tech lab table with undertop shelves and drawers Dimensions : L = 2500-2700 mm, W/D = 1000-1100 mm, H = 850-1100 mm Worktop Materials and thickness Solid hardwood, 40-45 thickness Material t...



SPECIFICATION

  • Design and Tech lab table with undertop shelves and drawers

  • Dimensions : L = 2500-2700 mm, W/D = 1000-1100 mm, H = 850-1100 mm

Worktop

  • Materials and thickness Solid hardwood, 40-45 thickness

  • Material treatment boiled, sanded (polished), treated and varnished

  • Built-in vice With integrated woodworking face simple vice at each corner on the long side of the table, single lever, wooden. In total 4 vices per table

Frame

  • Painting Thermally painted (powder coated) tubular (square pipe) frame

  • Additional reinforcement Vertical supports (legs) and horizontal  bars to withstand lateral forces and for increased stability

  • Bearing element wall thickness tube element wall thickness not less than 3 mm

Shelves and Drawers

  • Shelves integrated in the table structure open 2 shelves from short end till middle of the table

  • Quantity 2 columns of drawers for storage of small size tools

Electric Connections

  • Power Built-in power receptacles, 6 receptacles per table, located in top center

  • Type Power receptacles shall be European type (Schuko) with grounding contact

  • Ingress protection  Receptacles - IP44
