Demonstrating reflection, refraction, polarization and diffraction using microwaves

Order Code: 24258219.2

Category: General Lab Equipment V

It consists of a microwave transmitter Wave transmitter: Gunn diode 10.7GHz (λ=2.8cm) Power 30W voltage (10-12)V to (2 - 3.5)V. Cylindrical case with a diameter of 83mm and a length of 70mm. Overall length...



SPECIFICATION

  • It consists of a microwave transmitter

  • Wave transmitter: Gunn diode 10.7GHz (λ=2.8cm)

  • Power 30W voltage (10-12)V to (2 - 3.5)V.

  • Cylindrical case with a diameter of 83mm and a length of 70mm.

  • Overall length 225 mm.

  • Receiver: Similar in construction to the transmitter.

  • Probe detector: silicon microwave diode same as the receiver but mounted on a short, vertical, non-metallic rod.

  • Probe base with 4 plugs for connection to the external circuit with dimensions (75x50x135)m.

  • A microwave receiver, a power source, a diode diode, a protractor

  • An aluminum reflector of dimensions 200x300mm

  • An aluminum reflector of dimensions 50x300mm

  • An aluminum reflector of dimensions 300x300mm

  • An acrylic/beige reflector of dimensions 300x300x3mm

  • A semi-transparent reflector with size 300x300mm

  • APolarizing Grid with size 190x300mm, a Digital Multimeter, a BNC t Cable and a BNC Cable.
