DDS Function Generator
Order Code: 23246829.5
Category: General Lab Equipment II
Technical Specifications Description Type of Product DDS Signal / Function Generator with Counter ( with USB) Sine Wave Frequency 0-60MHz Square/Traingle, Wave 0-15MHz Puls Wa...
SPECIFICATION
Technical Specifications
| Description | |
| Type of Product | DDS Signal / Function Generator with Counter ( with USB) |
| Sine Wave Frequency | 0-60MHz |
| Square/Traingle, Wave | 0-15MHz |
| Puls Wave Frequency, TTL Digital Wave | 0-6MHz |
| Frequency, Arbitrary Wave Frequency | |
| Puls Width Adjustment | 30nS-4000S |
| Square Wave Rise Time | <=15ns |
| Min. Frequency Resolution | 0.01uHz |
| Frequency Accuracy | ±20ppm |
| Frequency Stability | ±1ppm /3 hours |
| Wave Form Length | 2048 points |
| Wave Form Sampling Rate | 266 Msa/s |
| Wave Form Vertical | 14 bits |
| Square/Pulse Wave | Overshoot <= 5% |
| Pulse Wave | Duty Cycle Adjustment 0.1% - 99.9% |
| Amplitude Resolution | 1mV |
| Output Impedence | 50Ohm ±10% |
| Offset Resolution | 0.01V |
| Phase Resolution | 0.1* |
| Level Rise/Fall Time | <= 20ns |
| Display | 2.4 Inch TFT Colore LCD |
| Arbitrary Wave | 1 to 60 |
| Power Supply | DC5V ±0.5V |
| Product Size | 194mm x 178 mm x 69mm |
| Product Weight | 1.2kg |
| Warranty | 1 Year |
