Control Valve Characteristics Trainer

Order Code: 52250 - 52

Category: Process Control Trainers

The Control Valve Characteristics Trainer (CVCT) is the system which outlines basics of control Valve, its characteristics. Order Code Description 52250 Control Valve Charac...



SPECIFICATION

The Control Valve Characteristics Trainer (CVCT) is the system which outlines basics of control Valve, its characteristics.

Order Code

Description

52250

Control Valve Characteristics Trainer (1 no. Valve) w/o Optional 52203 to 52205

52251

Control Valve Characteristics Trainer (2 no. Valve) w/o Optional 52203 to 52205

52252

Control Valve Characteristics Trainer (3 no. Valve) w/o Optional 52203 to 52205


Keywords:

  1. Equal Percentage Characteristics.
  2. Linear Characteristics.
  3. Quick Opening Characteristics.


Range of Experiments:

  1. Control valve characteristics.
  2. Study of Equal % characteristics.
  3. Study of linear characteristics.
  4. Study of ON-OFF/Quick opening characteristics.
  5. Study of control valve sizing.
  6. Study of control valve noise.
  7. Study of control Valve calibration and stroke checking.


Features:

  1. Compact Ergonomic Design.
  2. User Friendly, Self Explanatory Systems.
  3. Robust Construction.
  4. Training Manual for Operation Eas
  5. Caster wheel mounted movable frame.
  6. System Dimensions- 5 Ft. (L) X 3 Ft. (W) X 4 Ft. (H)


Services Required:

  1. Electric Supply of 1f 230 VAC, 50Hz.
  2. Water supply and drainage arrangement.
  3. Clean, Dry, Compressed air supply at 2.1 Kg/cm .
