Complete micro strip trainer

Order Code: 24257358.1.68

Category: General Lab Equipment V

Microwave source (VCO) Low-pass filter (LPF) Wilkinson power divider (PD) Ring resonator (RR) Three-port circulator (CIR) MMIC amplifier (AMP) Patch antenna (ANT) SMA coaxial connector (PP...



SPECIFICATION

  • Microwave source (VCO)

  • Low-pass filter (LPF)

  • Wilkinson power divider (PD)

  • Ring resonator (RR)

  • Three-port circulator (CIR)

  • MMIC amplifier (AMP)

  • Patch antenna (ANT)

  • SMA coaxial connector (PPC)

  • 50 ohm coaxial termination (MT)

  • 20 dB attentuator (ATT)

  • Directional coupler (DC)

  • Matched load (ML)

  • Rate-race hybrid coupler (RRH)

  • Unknown load & shunt stub (ZT)

  • PIN dioade modulator (PIN)

  • d.c. biasing unit (BL)

  • Crystal detector (D)

  • Coaxial short-circuit termination (SC)

  • Coaxial open-circuit termination (OC)

  • SMA plug - BNC jack adaptor (ADR)

Features

  • Comprehensive theory & experimental manual

  • Latest microwave technology : 2.4 to 3.4GHz VCO

  • 2 to 4GHz PIN diode modulator

  • Safe low power output

  • Components identified with inscribed reference number

  • Supplied in protective case

Technical data:

  • Dimensions (in protective case): 520 mm width x 380 mm depth x 180 mm height

  • Weight: gross 5.3 kg, net 4.8 kg

  • Scope of delivery: Power Supply ( 2×30V at 2.5A)
