Complete Experiment Setup For Electrical Machines And Drive

Order Code: 22235521.2.34

Category: General Lab Equipment I

Complete system for training in electrical machines (DC, AC, Three-Phase and Synchronous), as well as industrial frequency converters with minimally the following characteristics: Topics: Fundamentals Of Three-Phase Machines Equivalent Cir...



SPECIFICATION

Complete system for training in electrical machines (DC, AC, Three-Phase and Synchronous), as well as industrial frequency converters with minimally the following characteristics:

Topics:

  1. Fundamentals Of Three-Phase Machines
  2. Equivalent Circuit For An Asynchronous (Induction) Motor
  3. Torque, Efficiency And Optimum Magnetisation
  4. Circuit Wiring And Connection Of Components
  5. Setting Up A Drive And Testing Its Operation
  6. Parameter Setting For A Frequency Converter
  7. Learning The Key Menus
  8. Measurement Of Converter Output Voltage
  9. Effect Of Start Voltage
  10. Effect Of Start Compensation (Lxr Compensation)
  11. Response Of The Machine In The Absence Of Starting Voltage And Compensation
  12. Effect Of Slip Compensation
  13. Recording Of V/F Characteristic For A Machine Operating Without A Load, With And Without Compensation Of The Frequency Converter
  14. Design And Function Of Dc Machines
  15. Armature Reaction And Commutation
  16. Series-Wound Machines
  17. Possibilities For Changing Speed
  18. Energy Conversion
  19. Shunt-Wound Machines
  20. Operation At Constant Speed
  21. Self-Excitation
  22. Current-Voltage Characteristics
  23. Load Characteristics
  24. Possibilities For Changing Speed And Adjusting For Load
