Cavitation in pumps
Order Code: 24258098.34
Category: General Lab Equipment V
Cavitation in pumps: Visualisation of cavitation effects in a transparent pump; how speed, inlet pressure, flow rate and temperature affect cavitation. Features: visualisation of cavitation effects in a transparent pump, continuously adju...
SPECIFICATION
Cavitation in pumps: Visualisation of cavitation effects in a transparent pump; how speed, inlet pressure, flow rate and temperature affect cavitation.
Features:
-
visualisation of cavitation effects in a transparent pump, continuously adjustable pump speed, closed water circuit.
-
Learning objectives/experiments: formation of cavitation, observation of cavitation effect, how speed, inlet pressure, flow rate and temperature affect cavitation.
Specification:
-
visualisation of cavitation in centrifugal pumps
-
transparent pump housing and pipe at the inlet side
-
open impeller to observe the blades during operation
-
continuously adjustable pump speed via frequency converter
-
temperature control via heater and external cooling via water supply
-
flow measurement using rotameter
-
display of the pressures at inlet and outlet side of the pump via manometers,
-
digital display of speed, water temperature in the return and flow rate
-
closed water circuit with tank and temperature display.
-
Technical data: Centrifugal pump with drive motor, power consumption: 0,37kW, speed: 500...3300min-1, max. flow rate: 60L/min, max. head: 14m, Tank: 20L, Screw-in heater: 2kW. Measuring ranges, pressure (inlet): -1...0bar, pressure (outlet): 0...1,5bar, temperature: 0...100°C, flow rate: 10...140L/min, 230V, 50Hz, 1 phase
