Calibration Of Thermocouple

Order Code: 14253

Category: Process Control Trainers

Introduction: Settling or sedimentation is the separation of solid particles from fluids under the gravitational force. When a solid particle moves in a fluid, then a number of Forces are acting on it: (1) the gravitational force, acting downward, (2...



SPECIFICATION

Introduction: Settling or sedimentation is the separation of solid particles from fluids under the gravitational force. When a solid particle moves in a fluid, then a number of Forces are acting on it: (1) the gravitational force, acting downward, (2)the buoyant force, acting upward, (3)the drag force, acting upward. When a particle fall in a fluid under constant force, e.g. force of gravity, then particle accelerates for some time, but when the accelerating force equals the Retarding force (Buoyant force and Drag force) then the resultant force acting on the particle will be zero, and particle quickly reaches velocity, which is the Maximum attainable under the circumstances and which is called the terminal Velocity.

Specifications: Heat Source:Provide with ceramic insulation.Temp. Controller:Digital Temperature Controller.0-200°C.Thermocouple:Standard 3 types of thermocouple (a)CR / Al (b)Cu-Constantan (c)Fe-Constantan
