Bending Moment Apparatus

Order Code: 22236099.34

Category: General Lab Equipment I

 Experimental Set-Up has been designed specifically to study the cantilever bending : different loading positions & other parameters. The set up is absolutely self contained and requires no other apparatus. Practical experience on this set ...



SPECIFICATION

 Experimental Set-Up has been designed specifically to study the cantilever bending : different loading positions & other parameters.
The set up is absolutely self contained and requires no other apparatus. Practical experience on this set up carries great educative value for Science and Engineering Students.

OBJECT:

  • Study of bending of a cantilever, its different loading positions & other parameters.


FEATURES:

  • The Complete Experimental Set-up consists of following items:
  • A cantilever of steel material.
  • A firm clamping device to hold the cantilever horizontally.
  • Various loads with hanger : Total Wt. 500gm (Tow sets 5 X 50gm)
  • Meter scale : Length of 50cm Wooden .
  • Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Experimental procedure, Report Suggestions and Book References.
