Application/Scope    dehydrating    high-value    products    that    are    too    sensitive    for conventional drying

Features

• Monitoring software (Lyologger) to connect unit to PC

• Possibility of freezing samples inside the condenser

• Quick defrosting thanks to heating outside the condenser which allows the ice block to be easily removed,

• Vacuum pump outside the cabinet

• Double login feature; operator and administrator

• Plug and play freeze-dryer

• Compact bench mounted table-top unit

• Shelves temperature controlling (up to +70°C)

• Air cooled refrigeration

• Many accessories allowing freeze drying in ampoules, vials, bulk

• Possibility to work in AUTOMATIC; SEMIAUTOMATIC AND MANUAL mode.

• Possibility to save up to 4 different recipes with 10 steps each

• Each recipe with 4 selectable processes: stop, freezing, cool vacuum and heat shelves

• Chamber with manifold and stoppering

• IP. 0, Oox 5596 - Li-tiai(i. NR[3. I Exit:ail.loPf7,2vi!xi)hr,..).-:,fr- I .....    .J    La.    W 1/2V I t

Performance Specifications

•         ICE CONDENSER

•         Condensation surface m2 0,25    4

•         Minimum temperature (T. + 21°C) -83 ±3    4

•         Ice capacity 8 (6 kg/24 h)    4

•         Material AISI - 316L    2

•         REFRIGERATION UNIT

•         Number of compressors 2    3

•         Hermetic type One stage    3

•         Refrigeration power (at 35°C) 800    3

•         Refrigerent (free of CFCs) R-507 / R-23    3

•         Refrigeration of the unit By air circulation    3

•         Other requirements    3

•         Installation and Commissioning -to be indicated    1

•         Operation and Service Manuals- All Manuals in English    2

•         Warranty and Nearest service Centre —to be indicated    1

•         Brochures for the equipment to be provided during quotation    3
