Anthropometry Kit

Order Code: 22235682.1.2

Category: General Lab Equipment I

List of instruments in the kit:- 1.2.1 A–226 Anthropometer: to measure only the vertical dimensions of the human body. measuring range: ≤ 2500 mm,  instrument weight: ≤ 1.5 kg must contain stabilizer(base),&n...



SPECIFICATION

  • List of instruments in the kit:- 1.2.1 A–226 Anthropometer: to measure only the vertical dimensions of the human body.
    • measuring range: ≤ 2500 mm,
    • instrument weight: ≤ 1.5 kg
    • must contain stabilizer(base), spirit level, needle with sleeve( ranging from 30 to 380 mm) and the instrument.
  • 1.2.2 K–211Spreading Caliper: to measure the dimensions of the head
    • measuring range: 0 – 500 mm,
    • instrument weight: ≤ 200 g
    • Made of stainless with removable magnifier(digital reading )
  • 1.2.3 P–216 Pelvimeter: to measure the width and depth of chest, shoulder, pelvis etc
    • measuring range: 0 – 500 mm,
    • instrument weight: 215 g, 1.2.4 T–520 Modified Thoracometer:to measure the length of the foot
    • measuring range: 0 – 400 mm,
    • instrument weight: 260 g,
  • 1.2.5 v–372 small height rod: to measure vertical dimensions of the lower extremity.
    • measuring range: 20 – 106 mm,
    • instrument weight: 220 g 1.2.6 m–222 sliding caliper:
    • measuring range: 0 – 230 mm,
    • instrument weight: 193 g
    • 1.2.7 Best II K–501 Caliper: for standard measuring of skinfold thickness
    • measuring range: 0 – 80 mm (0 –120 mm),
    • instrument weight: 273 g,
    • measuring tip diameter: 3 mm, nominal compressive strength of the tips: 2 N, caliper dimensions: 142 x 116 x 10 mm
  • 1.2.8 Soft Metric Tape :for girth(waist) measurement
    • measuring range: 1 – 1,500 mm,
    • instrument width: 18 mm
  • 1.2.9 Bag with different pockets to secure all above anthropometric measuring tools
  • Document : user guide written in English
